TriClamp Afdichtingen
Resultaten filteren
close
Flensdiameter
Meer weergeven
Maatvoering
Materiaal
(koppel)maat
Meer weergeven
Kleur
Afmeting
Meer weergeven

TriClamp Afdichtingen

TriClamp Afdichtingen
Triclamp pakking met Lip - (ISO) - VITON - FPM
Triclamp pakking met Lip - (ISO) - VITON - FPM
ISO
1 Dag
€ 89,50
Triclamp pakking - (ISO) - PTFE
2 Varianten
Triclamp pakking - (ISO) - PTFE
ISO
1 Dag
Vanaf
€ 45,90
Triclamp pakking met Lip - DIN - EPDM
12 Varianten
Triclamp pakking met Lip - DIN - EPDM
DIN
Levertijd 3 - 4 - Dag(en)
Vanaf
€ 1,75
done Persoonlijk deskundig advies
done 25 jaar ervaring
done Snelle levertijden
done Scherpe prijzen
Triclamp pakking met Lip - (ISO) - EPDM
7 Varianten
Triclamp pakking met Lip - (ISO) - EPDM
ISO
1 Dag
Vanaf
€ 20,46
Triclamp pakking met Lip - INCH - EPDM
11 Varianten
Triclamp pakking met Lip - INCH - EPDM
INCH | 1"
1 Dag
Vanaf
€ 14,08
Triclamp pakking met Lip - INCH - VITON - FPM
18 Varianten
Triclamp pakking met Lip - INCH - VITON - FPM
INCH | 1"
1 Dag
Vanaf
€ 21,20
Triclamp Pakking INCH - PTFE
2 Varianten
Triclamp Pakking INCH - PTFE
INCH | 1-1/2"
1 Dag
Vanaf
€ 19,84
Triclamp pakking met Lip - DIN - NBR
23 Varianten
Triclamp pakking met Lip - DIN - NBR
DIN
Levertijd 3 - 4 - Dag(en)
Vanaf
€ 2,05
Triclamp pakking met Lip - DIN - Silicone - VMQ
12 Varianten
Triclamp pakking met Lip - DIN - Silicone - VMQ
DIN
Levertijd 5 - 7 - Dag(en)
Vanaf
€ 3,45
done Persoonlijk deskundig advies
done 25 jaar ervaring
done Snelle levertijden
done Scherpe prijzen
Triclamp pakking - DIN - PTFE
11 Varianten
Triclamp pakking - DIN - PTFE
DIN
Levertijd 5 - 7 - Dag(en)
Vanaf
€ 19,79
Triclamp pakking met Lip - DIN - VITON - FPM
9 Varianten
Triclamp pakking met Lip - DIN - VITON - FPM
DIN
Levertijd 3 - 4 - Dag(en)
Vraag offerte aan
request_quote
Triclamp pakking met Lip - DIN - NBR - Metal Detectable
9 Varianten
Triclamp pakking met Lip - DIN - NBR - Metal Detectable
DIN
Levertijd 3 - 4 - Dag(en)
Vraag offerte aan
request_quote
Triclamp pakking met Lip - INCH - NBR
22 Varianten
Triclamp pakking met Lip - INCH - NBR
INCH | 1"
Vanaf
€ 3,26
Triclamp pakking met Lip - INCH - NBR - Metal Detectable
11 Varianten
Triclamp pakking met Lip - INCH - NBR - Metal Detectable
INCH | 1"
Levertijd 4 - 5 - Dag(en)
Vanaf
€ 19,50
Zuivelafdichting - MINI - Envelop ring
Zuivelafdichting - MINI - Envelop ring
INCH | 3/4"
Vandaag voor 15:00 besteld, zelfde dag verzonden
€ 19,29
Vergelijken

Product/Attribute GYLON® BIO-PRO PLUS GYLON BIO-PRO® Turf-Flex® Turf-Steel® PFTE PFTE/EPDM Envelope PTFE/FKM Envelope Peroxide Cured FKM Next Generation Peroxide Cured EPDM Next Generation Platinum Cured Silicone Next Generation Buna
Temperature Range -260°C to 260°C ('-450°F to 500°F) -260°C to 260°C (-450°F to 500°F) -29°C to 150°C (-20°F to 500°F) -198°C to 288°C (-325°F to 550°F) -73°C to 260°C (-100°F to 500°F) -30°C to 150°C (-22°F to 300°F) -30°C to +170°C (-22°F to 338°F) -34°C to 205°C (-29°F to 300°F) -30°C to 150°C (-22°F to 300°F) ´-40°C to 230°C (-40°F to 450°F' -34°C to 93°C (-29°F to 200°F)
Pressure Range Up to 55 bar Up to 55 bar Clamp**** Clamp**** Clamp**** Clamp**** Clamp**** Clamp**** Clamp**** Clamp**** Clamp****
Vaccuum Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Chemical Resistance Universal* High Universal* High Universal* Universal* Universal* Medium to High Medium Medium Low to Medium
Material 100% PTFE PTFE + Pigment + Filler PTFE + EPDM PTFE + 316SS 100% PTFE PTFE/EPDM PTFE/FKM  100% FKM Peroxide Cured 100% EPDM Peroxide Cured   100% Buna
Traceability Yes On Demand On Demand On Demand On Demand On Demand On Demand Yes Yes Yes  On Demand
CIP Processes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
SIP Processes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Dimensional stability Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Easy removal/non-stick Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Shelf life Unlimited Unlimited 10 Years 10 Years 10 Years 10 Years 10 Years 10 Years 10 Years 10 Years 10 Years
Service Life Unlimited** Unlimited** Application Dependent*** Application Dependent*** Application Dependent*** Application Dependent*** Application Dependent*** Application Dependent*** Application Dependent*** Application Dependent*** Application Dependent***
TA-LUFT + Blowout Yes No No No No No No No No No No
FDA Compliance FDA 21 CFR177.1550 FDA 21 CFR17.1550 FDA 21 CFR177.1550 FDA 21 CFR177.1551 FDA 21 CFR177.1552 FDA 21 CFR177.1553 FDA 21 CFR177.1554 FDA 21 CFR177.2600 FDA 21 CFR177.2600 FDA 21 CFR177.2600 FDA 21 CFR177.2600
EC1935/2400 & EC2023/2006 Yes + GMP Yes + GMP Yes + GMP Yes + GMP No No No Yes + GMP Yes + GMP Yes + GMP No
USP Class VI <87> & <88> at 121°C <87> & <88> at 121°C <87> & <88> at 121°C <87> & <88> at 121°C <87> & <88> at 121°C <87> & <88> at 70°C <87> & <88> at 70°C <87> & <88> at 121°C <87> & <88> at 121°C <87> & <88> at 121°C No
Phthalate Free Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Silicone Free Yes Yes Yes Yes Yes Yes Yes Yes Yes No Yes
BAM Tested Yes Yes No No No No No No No No No
ADI Free Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes No
Hydrocheck No Yes No No No No No No No No No
3A 18-30 No No No No No No No Class I Class II Class I Class III
3A 20-27 Yes Yes Yes Yes Yes Yes Yes No No No No
Hygienic Design per EHEDG Yes No No No No No No No No No No
NSF 61 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
62.Bfr Yes No No No No No No No No No No
Application Pharma, Food, SIP, CIP, Hygienic Design, Ultra-Low Adhesion, High Purity Demands, Sustainable Cleaning Pharma, Food, Rough SIP & CIP, Well Known and Proven Gasket Pharma, Food, Rough, SIP & CIP, Well Known & Proven Gasketing Material Pharma, Food, Rough, SIP & CIP, Well Known & Proven Gasketing Material Pharma, Food, High Chemical Resistance,& Temperature Range, SIP, CIP Pharma, Food, High Chemical Resistance & Temperature Range, SIP, CIP Pharma, Food, High Chemical Resistance & Temperature Range, SIP, CIP Pharma, Food, Medium to High Chemical Resistance Pharma, Food, Medium to High Chemical Resistance, Good Temperature Range, SIP, CIP Pharma, Food Medium to High Chemical Resistance, Good Temperature Range, SIP, CIP Pharma, SIP , CIP, Good Chemical Resistance, Good Temperature Range, SIP, CIP
*Except certain alkali metals and fluorinating agents     **Depending on application parameters ***Service life is dependent upon specific application and installment by the customer ****Pressure Limit of the Clamp



ID ID OD OD Bead Series A (DIN32676) Series B (ISO1127) Series C (ASME BPE) ISO 2852 SMS 3019 BS 4825-3 SCH 5 BS Special Size
Inch mm Inch mm Inch/mm
0.17 4.20 0.86 21.80 0.80/20.20               X
0.19 4.80 0.86 21.80 0.80/20.20     1/4"
0.24 6.20 0.86 21.80 0.80/20.20 DN06
0.28 7.20 0.86 21.80 0.80/20.20   DN06
0.31 8.00 0.86 21.80 0.80/20.20     3/8"
0.32 8.20 0.86 21.80 0.80/20.20 DN08
0.38 9.60 0.86 21.80 0.80/20.20     1/2"     1/2"
0.41 10.50 0.86 21.80 0.80/20.20   DN08
0.48 12.20 0.86 21.80 0.80/20.20               X
0.56 14.20 0.86 21.80 0.80/20.20   DN10
0.63 16.00 0.86 21.80 0.80/20.20     3/4"     3/4"
0.88 22.30 1.34 34.00 0.80/20.20     1" Type A
*21.8mm gaskets do not have a ferrule bead (Inlcuding 1* Type A) 21.8mm sizes utilize size: 13HHM-304-050/075
0.39 10.00 1.34 34.00 1.08/27.50
0.40 10.20 1.34 34.00 1.08/27.50 DN10     DN12
0.41 10.50 1.34 34.00 1.08/27.50               X
0.43 10.90 1.34 34.00 1.08/27.50       DN12.7
0.56 14.20 1.34 34.00 1.08/27.50               X
0.61 15.40 1.34 34.00 1.08/27.50       DN17.2
0.64 16.20 1.34 34.00 1.08/27.50 DN15       DN18
0.72 18.30 1.34 34.00 1.08/27.50               X
0.77 19.50 1.34 34.00 1.08/27.50       DN21.3
0.80 20.20 1.34 34.00 1.08/27.50 DN20
0.88 22.30 1.34 34.00 1.08/27.50               X
Above sizes utilize clamp size: 13MHHM-304-34mm (Including 1" Type A)
0.40 10.20 2.00 50.50 1.71/43.50               X
0.56 14.20 2.00 50.50 1.71/43.50               X
0.64 16.20 2.00 50.50 1.71/43.50               X
0.72 18.30 2.00 50.50 1.71/43.50   DN15
0.80 20.20 2.00 50.50 1.71/43.50               X
0.88 22.30 2.00 50.50 1.71/43.50     1"
0.90 22.80 2.00 50.50 1.71/43.50       DN25 DN25
0.94 23.90 2.00 50.50 1.71/43.50   DN20
1.03 26.20 2.00 50.50 1.71/43.50 DN25
1.18 29.90 2.00 50.50 1.71/43.50   DN25
1.20 30.50 2.00 50.50 1.71/43.50
1.24 31.50 2.00 50.50 1.71/43.50       DN33.7 DN33.7
1.27 35.00 2.00 50.50 1.71/43.50 DN32
1.38 35.00 2.00 50.50 1.71/43.50     1.5"     1.5"
1.41 35.80 2.00 50.50 1.71/43.50       DN38 DN38
1.50 38.20 2.00 50.50 1.71/43.50 DN40
1.52 38.60 2.00 50.50 1.71/43.50               X
Above sizes utilize clamp size: 13MHHM-304-100/150
1.49 37.80 2.52 64.00 2.22/56.50       DN40
1.52 38.60 2.52 64.00 2.22/56.50   DN32
1.75 44.50 2.52 64.00 2.22/56.50   DN40
1.78 45.30 2.52 64.00 2.22/56.50             1.5"
1.88 47.70 2.52 64.00 2.22/56.50     2"     2"
1.92 48.80 2.52 64.00 2.22/56.50       DN51 DN51
1.98 50.20 2.52 64.00 2.22/56.50 DN50
Above sizes utilize clamp size: 13MHHM-304-200
2.22 56.50 3.05 77.50 2.78/70.50   DN50
2.26 57.40 3.05 77.50 2.78/70.50             2"
2.38 60.40 3.05 77.50 2.78/70.50     2.5"     2.5"
2.38 60.50 3.05 77.50 2.78/70.50       DN63.5 DN63.5
Above sizes utilize clamp size: 13MHHM-304-250
2.61 66.20 3.58 91.00 3.29/83.50 DN65
2.64 67.00 3.58 91.00 3.29/83.50       DN70
2.72 69.00 3.58 91.00 3.29/83.50             2.5"
2.85 72.30 3.58 91.00 3.29/83.50   DN65
2.88 73.10 3.58 91.00 3.29/83.50     3" DN76.1 DN76.1 3"
Above sizes utilize clamp size: 13MHHM-304-300
3.20 81.20 4.17 106.00 3.82/97.00 DN80
3.33 84.50 4.17 106.00 3.82/97.00   DN80
3.35 85.10 4.17 106.00 3.82/97.00       DN88.9 DN88.9   3"
Above sizes utilize clamp size: 13MHHM-V-304-300
3.84 97.60 4.67 119.00 4.33/110.00     4"     4"
3.85 97.80 4.67 119.00 4.33/110.00       DN101.6 DN114.3
3.94 100.20 4.67 119.00 4.33/110.00 DN100
Above sizes utilize clamp size: 13MHHM-304-400
4.33 109.90 5.12 130.00 4.80/122.00   DN100
4.35 110.50 5.12 130.00 4.80/122.00       DN114.3 DN114.3   4"
Above sizes utilize clamp size: 13MHHM-V-304-400
4.86 123.50 5.68 144.20 5.29/134.30     5"
Above sizes utilize clamp size: 13MHHM-304-500
4.93 125.20 6.10 155.00 5.75/146.00 DN125
5.30 134.70 6.10 155.00 5.75/146.01   DN125
5.35 135.90 6.10 155.00 5.75/146.02       DN139.7 DN139.7   5"
Above sizes utilize clamp size: 13MHHM-V-304-500
5.79 147.10 6.57 167.00 6.16/156.50     6"
Above sizes utilize clamp size: 13MHHM-304-600
5.91 150.20 7.20 183.00 6.85/174.00 DN150
6.43 163.30 7.20 183.00 6.85/174.00   DN150   DN168.3 DN168.3   6"
Above sizes utilize clamp size: 13MHHM-V-304-600
7.78 197.60 8.56 217.40 8.15/207.00     8"
Above sizes utilize clamp size: 13MHHM-304-800
7.88 200.20 9.19 233.50 8.86/225.00 DN200
8.43 214.10 9.19 233.50 8.86/225.00   DN200   DN219.1 DN219.1   8"
Above sizes utilize clamp size: 13MHHM-V-304-800
9.77 248.20 10.66 271.00 10.14/257.60 DN250*   10"
Above sizes utilize clamp size: 13MHHM-304-1000
10.49 266.50 11.32 287.60 11.00/279.40             10"
Above sizes utilize clamp size: 13MHHM-V-304-1000
11.81 300.00 12.56 319.00 12.17/309.00 DN300*   12"
Above sizes utilize clamp size: 13MHHM-304-1200
12.44 316.00 13.31 338.10 12.93/328.42             12"
Above sizes utilize clamp size: 13MHHM-V-304-1200
* Not included in the sanitary standard
